PB X4 & XX4

In the picture: PB XX4 bed, standard design in beech. Accessories: cabinet Rubens 2, beech.



Thanks to the reinforced construction and the use of specially designed actuators suitable for high loads, the PB X4 series beds are designed for people with increased body weight who require long-term care. The very stable design of the bed guarantees safe use, and the mattress support platform is constructed with a metal mesh for easy disinfection.

This high quality care bed has been especially designed for patients with a higher bodyweight and can also be used when a heavier mattress is necessary. This care bed is similar to our PB  526 and can be ordered in 2 different variations:

  • Maximum load of 250 kg PB X4
  • Maximum load of 350 kg PB XX4

Using its unlocked 4 to 6 high-class ball bearing casters the bed can easily be shifted. The continuous side bars can be lowered and slid onto each other that they pose no hindrance for entering or exiting the bed. This bed has been produced to withstand highest stresses and strains. The 4-sectioned lying area comes in the  standard dimensions of 100 cm x 200 cm, is made of an easy to clean metal mesh and individually adjustable using 2 single electric motors. In addition, the adjustability of the foot part is supported by 2 ratchets. On demand this bed can be equipped with a central break and is also available in other lying area dimensions. The PB X4 / PB XX4 is laterally accessible for patient lifts.

The 4-sectional lying surface is electrically adjustable between 40 cm and 80 cm (upper end of the lying area). All electronic components have been manufactured according to latest research and are in accordance with all valid safety requirements and standards. Every single adjustment option of the bed is comfortably controllable by using the splash-proof manual control switch and any single function can be individually locked. The very stable lifting mechanism has been designed to handle loads up to 250 kg / 350 kg naturally.

Standard colors


C1 Dark beech



Product details

1. Maximum safe working load 250 kg – X4 / 350 kg – XX4 4. Handset with lockable functions
2. High quality brake castors 5. Upholstered fronts (option)
3. Various dimensions of mattress support platform 6. Hidden feet (option)

Options

extendable mattress support platform • colours choice

Technical parameters

Safe working load: X4: 250,0 kg   |   XX4: 350,0 kg
Maximum user weight: X4: 200,0 kg   |   XX4: 300,0 kg
Mattress support platform height adjustment from 40 to 80 cm
Back rest adjustment: 0 ÷ 70°
Lower leg rest adjustment: 0 ÷ 20°
External dimensions (length × width): 207 × 132 cm
Clearance under the bed: approx. 16 cm
Total weight: X4: 150,6 kg   |   XX4: 156,6 kg
Castors: 100 mm with a brake



Functions of the rehabilitation bed
